| 1 | Fiber | G657A |
| 2 | Operating Wavelength(nm) | 1260~1650nm |
| 3 | Insertion Loss(dB) | ≦16.8dB ( W/Connector ) |
| 4 | Uniformity(dB) | ≦1.6dB |
| 5 | Return Loss(dB) | ≧55dB |
| 6 | PDL(dB) | ≧0.3dB |
| 7 | Directivity(dB) | ≧55dB |
| 8 | Connector Type | Input - LC/APC Simplex adaptor green |
| Output - 2.0mm cable LSZH yellow | ||
| 9 | Cable Type | Input- 2,0mm cable LSZH orange, output- 2.0mm cable LSZH yellow |
| 10 | Case | Metal(CNC) - Black |
| 11 | Operating Temperature(°C) | -40°C ~ +85°C |
